Roofing Service
Durable, energy-efficient, and custom-engineered roofing service solutions for industrial, commercial, and institutional structures.
At Pristicon Infratech Pvt. Ltd., we provide end-to-end roofing service solutions that combine structural integrity, thermal performance, and long-term durability. Our roofing systems are engineered to meet the functional and architectural demands of industrial, commercial, and institutional buildings, ensuring compliance with IS standards and local codes.
Our Roofing Service Expertise Covers
Pre-Engineered Building (PEB) Metal Roofing System
Structural Design and Analysis
- Standards Followed:
- IS 800:2007 – General construction in steel (Limit State Method)
- IS 875 (Parts 1–5) – Design loads for buildings and structures (dead load, live load, wind load, seismic loads, snow loads)
- IS 1893 (Part 1): 2016 – Earthquake resistant design of structures
- Design Software: STAAD.Pro, Tekla, and MBS for structural modeling, detailing, and load simulation.
- Load Considerations: Wind uplift, live maintenance loads, seismic zone classification, and thermal expansion are addressed in the design.
Roofing Material Specification
- Sheet Type: Trapezoidal profile sheets (Hi-Rib or Industrial Rib) or standing seam concealed-fix systems.
- Material:
- Galvalume Steel Sheets (55% Al-Zn alloy-coated), AZ-150 grade (as per ASTM A792 and equivalent Indian acceptance)
- Color Coated Steel conforming to IS 14246:2013 for pre-painted galvanized steel
- Yield Strength: Minimum 550 MPa
- Thickness: 0.47 mm to 0.60 mm TCT (Total Coated Thickness)
- Paint Coating: Polyester/RMP/SMP/PVDF as per project requirement and environmental exposure.
Purlins and Roof Support Members
- Material: Cold-formed Z and C purlins fabricated using IS 513 Grade D steel or equivalent
- Standard Followed: IS 801 – Design of cold-formed light gauge steel structural members
- Purlin Thickness: 1.6 mm to 2.5 mm (varies with span and loading)
- Fully integrated with the main frame using cleat connections, anchor bolts, and bracing systems as per IS 800.
Roof Slope and Drainage
- Typical Slope Range: 1:10 to 1:20 depending on site conditions, building width, and rainfall intensity (as per NBC 2016 Rainfall Data)
- Gutter & Downspout Design: Based on IS 2527 – Code of practice for fixing rainwater gutters and downpipes
- Materials: Pre-painted Galvalume/GI with anti-rust coating or PVC/HDPE downpipes.
Roofing Accessories
- Turbo Ventilators & Ridge Vents: Designed for passive ventilation in compliance with industrial building ventilation standards.
- Translucent Sheets: Polycarbonate sheets conforming to IS 14443 for natural daylighting
- Insulation: Glass wool or Rockwool (IS 8183 / IS 3144) for thermal and acoustic control
- Fasteners: Self-drilling screws with EPDM washers conforming to corrosion resistance class as per ISO 9223
Key Advantages of Our Roofing Service
